| Model | FOP3 | FOP4 |  | |
| Maximum height m | 3 | 4 | ||
| Standing platform load capacity kg | 150 | 150 | ||
| Load capacity of loading platform kg | 90 | 90 | ||
| Standing table size mm | 720*700 | 720*700 | ||
| Size of the cargo platform mm | 740*560 | 740*560 | ||
| Overall machine length (mm) | 1480 | 1480 | ||
| Machine width (mm) | 756 | 756 | ||
| Overall machine height (mm) | 1473 | 1805 | ||
| Minimum ground clearance height mm | 15 | 15 | ||
| Wheelbase (mm) | 1060 | 1060 | ||
| Minimum turning radius mm | 1480 | 1480 | ||
| Drive motor V/kw | 2*24V/0.5kw | 2*24V/0.5kw | ||
| Lifting motor V/kw | 24V/0.8kw | 24V/0.8kw | ||
| Machine travel speed (platform descent) km/h | 4 | 4 | ||
| Machine travel speed (platform raised) km/h | 0.8 | 0.8 | ||
| Rising/falling speed in seconds | 20/30 | 20/30 | ||
| Battery V/Ah | 2*12V/100 | 2*12V/100 | ||
| Charger V/A | 24V/10A | 24V/10A | ||
| Maximum climbing ability% | 10-15 | 10-15 | ||
| Maximum allowable angle for work/ | 2° | 2° | ||
| drive wheel mm | Φ305*100 | Φ305*100 | ||
| Front wheel mm | Φ200*50 | Φ200*50 | ||
| Machine weight kg | 840 | 870 | ||
*The factory reserves the right to modify materials and technical parameters. Please confirm before placing an order.
