| Product Model | GTJZ24 | GTJZ26 |
| Safe working load (kg) | 320 | 320 |
| Extended platform safe working load (kg) | 113 | 113 |
| Maximum working height (m) | 6 | 8 |
| Maximum platform height (m) | 4 | 6 |
| Dimensions of the work platform (length x width x height, m) | 1.7×0.75×1.1 | 1.7×0.75×1.1 |
| Overall dimensions of the machine (length x width x height, folded guardrail, m) | 1.9×1×2.1 | 1.9×1×2.2 |
| Overall dimensions of the machine (length x width x height, unfolded guardrail, m) | 1.9×1×1.7 | 1.9×1×1.8 |
| Platform extension size (m) | 0.5 | 0.5 |
| Minimum ground clearance (collapsed state, m) | 0.1 | 0.1 |
| Minimum ground clearance (collapsed state, m) | 0.19 | 0.19 |
| Wheelbase (m) | 1.7 | 1.7 |
| Minimum turning radius (inner/outer wheel, m) | 0／2.2 | 0／2.2 |
| Lift motor/drive motor (V/kW) | 24V／3kW | 24V／3kW |
| Machine travel speed (folded state, km/h) | 1.8 | 1.8 |
| Machine travel speed (folded state, km/h) | 0 | 0 |
| Rising/falling speed (seconds) | 80／30 | 80／30 |
| Battery (V/Ah) | 24V／150Ah | 24V／150Ah |
| Charger (V/A) | 24V／30A | 24V／30A |
| Maximum climbing ability (%) | 25 | 25 |
| Maximum allowable working angle (indoor/outdoor, °) | 1.5／3 | 1.5／3 |
| Tire (mm) | Steel track | Steel track |
| Whole machine weight (kg) | 1250 | 1350 |
*The factory reserves the right to modify materials and technical parameters. Please confirm before placing an order.
