| Model | SJY0.3-3 | SJY0.3-3.9 | SJY0.3-4.8 |
| Maximum height of platform (mm) | 3000 | 3900 | 4800 |
| Minimum height of platform (mm) | 630 | 700 | 830 |
| Work platform size (mm) | 1170×600 | 1170×600 | 1170×600 |
| Extended tabletop size (mm) | 500 | 500 | 500 |
| Rated load of the platform (kg) | 300 | 300 | 300 |
| Rise time (s) | 33 | 33 | 33 |
| Descent time (s) | 30 | 30 | 30 |
| Lifting motor (V/kW) | 12/0.8 | 12/0.8 | 12/0.8 |
| Charger (V/A) | 12/10 | 12/10 | 12/10 |
| Overall length (mm) | 1300 | 1300 | 1300 |
| Overall width (mm) | 740 | 740 | 740 |
| Overall height (mm) | 1880 | 1930 | 2030 |
| Whole machine weight (kg) | 360 | 420 | 475 |
| Battery (V/Ah) | 12/60 | 12/60 | 12/60 |
*The factory reserves the right to modify materials and technical parameters. Please confirm before placing an order.
