| Product Model | GTJZ04LD |
| Maximum working height (m) | 6 |
| Maximum platform height (m) | 4 |
| Safe working load (kg) | 200 |
| Extended platform load (kg) | 110 |
| Exterior height (upright/folded, m) | 2.03／1.67 |
| Dimensions (length x width, m) | 1.4×0.78 |
| Table size (length x width, m) | 1.29×0.7 |
| Platform extension length (m) | 0.55 |
| Minimum ground clearance (m) | 0.055 |
| Minimum turning radius (inside) | 360 ° in-situ rotation |
| Driving speed (km/h) | 3 |
| Maximum adjustable platform for supporting legs | Without legs |
| Maximum allowable angle for work (in both directions, °) | 1.5／3 |
| Maximum climbing ability (%) | 25 |
| Rise/fall time (s) | 25／25 |
| Battery (V/Ah) | 12/100, a total of 2 pieces |
| Charger (V/A) | 24/15 |
| Lifting/driving motor (kW) | 0.45／1.3 |
| Whole machine weight (kg) | 820 |
*The factory reserves the right to modify materials and technical parameters. Please confirm before placing an order.
