| Model | FSJY3 | FSJY3.9 | FSJY4.8 |
| Rated load of the platform (kg) | 300 | 300 | 300 |
| Maximum working height (mm) | 5000 | 5900 | 6800 |
| Maximum platform height (mm) | 3000 | 3900 | 4800 |
| Overall length (mm) | 1180 | 1180 | 1180 |
| Overall width (mm) | 760 | 760 | 760 |
| Overall height (mm) | 1830 | 1930 | 1990 |
| Work platform size (mm) | 1170×600 | 1170×600 | 1170×600 |
| Extended tabletop size (mm) | 500 | 500 | 500 |
| Minimum ground clearance height (mm) | 60 | 60 | 60 |
| Wheelbase (mm) | 990 | 990 | 990 |
| Minimum turning radius (mm) | 1200 | 1200 | 1200 |
| Drive motor (V/kW) | 2×24/0.4 | 2×24/0.4 | 2×24/0.4 |
| Lifting motor (V/kW) | 24/0.8 | 24/0.8 | 24/0.8 |
| Machine travel speed (platform descent, km/h) | 4 | 4 | 4 |
| Machine travel speed (platform raised, km/h) | 0.8 | 0.8 | 0.8 |
| Rise/fall time (s) | 20/30 | 20/30 | 20/30 |
| Battery (V/Ah) | 2×12/80 | 2×12/80 | 2×12/80 |
| Charger (V/A) | 24/10 | 24/10 | 24/10 |
| Maximum climbing ability (%) | 10–15 | 10–15 | 10–15 |
| Maximum allowable angle for work (°) | 2 | 2 | 2 |
| Drive wheel (mm) | φ230×80 | φ230×80 | φ230×80 |
| Front wheel (mm) | φ150×60 | φ150×60 | φ150×60 |
| Whole machine weight (kg) | 530 | 640 | 640 |
